Steerman SX Load Moving Skate System

Name: Steerman SX Load Moving Skate System
Brand: Steerman Load Moving Systems
Price: 1388.4200 GBP
Availability: InStock

Brand:

Capacity

10,000Kgs up to 60,000Kgs
(10 tonne - 60 tonne)

Description

The Steerman SX Load Moving Systems is the choice for professional load movers, these systems have been developed over a number of years to ensure total ease of operation, maximum safety, and premier build quality and reliability.

Model/Capacity:

Accessories 1:

£1,388.42 ex VAT

£1,666.10 inc VAT

Add to cart

Add to quote

Related products

Steerman BVA Hydraulic Toe Jack

BVA

The Steerman BVA Industrial Hydraulic Toe Jack. A quality manufactured hydraulic jack with lifting toe, designed for working in confined spaces and lifting heavy machinery or containers off the floor ready for moving skates/systems to be positioned underneath

£419.48 ex VAT

£503.38 inc VAT

More info

Description
Specifications
Brand benefits
Reviews (0)
Q & A

The Steerman SX Load Moving Systems is the choice for professional load movers, these heavy-duty systems have been developed over a number of years to ensure total ease of operation, maximum safety and premier build quality and reliability. These kits three-piece kits are ideal for transporting/repositioning all types of heavy loads like machinery, steel structures, generators, etc. If your load has an unfavourable centre of balance, a second front steerable skate can be placed strategically to aid stability while the load is being repositioned.

The robust towing bar in connection with the unique turntable on large-diameter thrust bearings allows effortless steering of the load. The rear skates are aligned parallel by means of a tie rod and kept in position, thus ensuring time-saving and smooth transportation of the load.

The skates are powder coated and all connecting elements are corrosion-resistant. The highest safety requirements have been considered.

Each kit comprises 1 Front skate c/w handle/towing arm PLUS 2 rear skates (1Pair) c/w connecting bar.

Model	Capacity of Complete Set	Capacity of Front Skate Only	Capacity Rear Skates only	Overall Height of both front/rear	Boxed Weight Complete Set
SX10	10,000Kgs	5,000Kgs	5,000Kgs / Pair	102mm	54Kgs
SX20	20,000Kgs	10,000Kgs	10,000Kgs / Pair	102mm	76Kgs
SX30	30,000Kgs	15,000Kgs	15,000Kgs / Pair	110mm	136Kgs
S60	60,000Kgs	30,000Kgs	30,000Kgs / Pair	170mm	302Kgs

All of the above kits can have skating body handles removed from the skating body.

The rear connecting bars can be removed from the rear skates creating smaller components that are lighter and easier now to be packed away for both transportation and storage.

Main Features of the Steerman Load Moving Systems

• The modular design ensures an extremely simple operation and simultaneously offers a wider range of combinations.

• The construction of the load-moving systems is extremely robust and resistant to distortion.

• The skates are smooth-running and provide an incredibly low rolling resistance even with the heaviest loads.

• Twin rollers (instead of one wide roller) ensure low rolling resistance even at a narrow curve radius.

• The universal joint suspension of the roller groups contributes to positive contact when travelling over uneven floors.

• The roller wheels are manufactured with abrasion-resistant, elastic polyamide. They are protected against breakage and have high chemical resistance.

• Each individual roller is made from high-tensile material which ensures extremely quiet running.

• The rollers are suitable for all in-plant floors and will not damage normal floor covering.

• The load-moving systems can be easily dismantled and facilitate transport even in small trucks.

• The load-moving systems have been developed for professional applications and are practically maintenance-free.

• All rollers are provided with two encapsulated, lifetime lubricated ball bearings.

• The front steering skate is equipped with an amply dimensioned axial ball bearing underneath the turntable.

• The front and rear skates are available individually.

Each kit comprises 1 Front skate c/w handle/towing arm PLUS 2 rear skates (1Pair) c/w connecting bar

Model	Capacity of Complete Set	Capacity of Front Skate Only	Capacity Rear Skates only	Overall Height of both front/rear	Boxed Weight Complete Set
SX10	10,000Kgs	5,000Kgs	5,000Kgs / Pair	102mm	54Kgs
SX20	20,000Kgs	10,000Kgs	10,000Kgs / Pair	102mm	76Kgs
SX30	30,000Kgs	15,000Kgs	15,000Kgs / Pair	110mm	136Kgs
S60	60,000Kgs	30,000Kgs	30,000Kgs / Pair	170mm	302Kgs

All of the above kits can have skating body handles removed from the skating body. The rear connecting bars can be removed from the rear skates creating smaller components that are lighter and easier now to be packed away for both transportation and storage.

Steerman is a worldwide supplier of load-moving equipment with outlets throughout Europe, Africa, Asia, and North America. Originally designed for the professional load mover, these systems have been developed over a number of years to ensure total ease of operation and maximum safety. All Steerman load-moving skates comprise a steerable front section and a pair of adjustable rear trolleys. These innovative systems are available in capacities from 2 to 100 tonnes and can be stripped down to components for easy transportation.
